J-9060-HEFEI Gere-tech International Trade Co, Ltd.

Machine	J-9060
Machine Name	9060 cutting machine Processing function is efficient 9060 type laser engraving cutting machine
Laser type	Hermetic Co2 glass tube
Driving system	Stepper motor
Laser power	60W/80W/100W/130W(Optional )
Total power	≤2000W
Working area	900*600mm
Max moving speed	0-3000mm/min
Worktable Location precision	±0.1mm
Mini shaping character	Chinese character,22mm ,English Letter 11mm
Data transfer interface	USB
System environment	Windows 2000/Windows XP /Win 7
Cooling Way	Water cooling and protection system
Compatible software	Coredraw, Auto CAD
Cutting thickness	0-20mm(depends on different materials)
Operating temperature	0-45℃
Operating humidity	5-95%
Machine dimension	L1350W940H570mm
Net weight	120KG
Gross weight	150KG

Optional Item:

Motorized up-down platform included (if no need, deduct usd50)

Rotary device：

simple device : +USD35

Professional type :+ USD150

Applicable Materials For Reference:

Material	Engraving	Cutting	Material	Engraving	Cutting
Natural Wood	√	√	Paper	√	√
Acrylic	√	√	Mylar	√	√
Glass	√	×	Pressboard	√	√
Double Color Plate	√	√	Rubber	√	√
Bamboo	√	×	Plywood	√	√
Cloth	√	√	Plastic	√	√
Leather	√	√	Ceramic	√	×
Marble	√	×	Coated Metal	√	×
Stone	√	×	Other Non-metallic	√

FAQ:

1.Q:Why should you choose us?

A:If you choose us, you will get best quality, best service, best price, best warranty.

2.Q:I'm not familiar with the machine.

A:You just need to tell us materials, working size and thickness. I will recommend you the right machine.

3.How to operate the machine

A:We will deliver English manual and video with the machine to you. If you still need our help, please contact us.

4.Q:How can I get the sample to check you quality ?

A:If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.

5.Q:Do the machine can be customized according my requirements?

A:Sure,we have a strong technical team and have rich experience. Our goal is to make you satisfied.

6.Q:Can you arrange the shipment for me?

A:We can arrange the shipment for our clients accordingly by sea and air. Trading terms FOB, CIF, EXW are available.
